ABSOLUTEDigimaticIndicatorID-CNX(DigimaticS1supported)SERIES543̶StandardType•ID-CSeriesisanext-generationindicatorwithmanynewfunctions,supportingbidirectionalcommunication.Withtheadditionoftheappropriatedatacableandsoftware,remotezerosettingandgagesettingcanallbeimplementedfromaconnectedPC,therebyimprovingyourworkefficiency.•Thedigitaldisplayandanalogbarindicationshelpyoutointuitivelyreadtheapproachtotheoriginandtolerancevalues.•Thenextcalibrationduedatecanbesetwithanalarmtoimproveinstrumentmanagement.•TheABS(ABSOLUTE)scalerestoresthelastoriginposition*automaticallywhentheindicatoristurnedon,andrealizeshighreliabilitybyeliminatingover-speederrors.•Equippedwithadataoutputportthatenablesincorporationintomeasurementnetworkingandstatisticalprocesscontrolsystems.*Referto“OriginSettingofDigimaticIndicators”onpage2-33.Measuringrange12.7mm543-700BLowmeasuringforcemodel543-705BMeasuringrange25.4mm543-720BMeasuringrange50.8mm543-730BTipsFordetailsofeachmark,seeIntropage13.Referto"Optionalaccessories"onpage2-32.2-3
| <
|
> |
>>
